AC diagnosis Smart Sensor
SKU: 22EN001
$ 99.00
$ 69.00
Excluding Sales Tax
Quantity:
1

PREMIUM Service

Enjoy the full potential of what AC diagnosis has to offer with exclusive features that will keep you up-to-date and in touch with your customers. The team will be on hand to offer support when needed, making sure your PREMIUM experience is of the highest standard.



PACKAGE

- No. 1 Smart Bluetooth IoT sensor with battery

- No. 2 attachment system

- Robust box with insert foam for great protection

- Free download iOS and Android app

- Unlimited A/C performance test with digital reports and log test result

​

VEHICLE COVERAGE:

Compatible with refrigerant R-134a and R-1234yf



SPECIFICATIONS:

- Communication: Bluetooth Low Energy 5.0 with automatic power-saving

- Smart IoT technology integrates refrigerants performance chart

- Working frequency: ISM frequency 2.402~2.480GHz

- Spread spectrum method: FHSS

- Transmitting power: 0dBm

- Safety standard: AES 128bit

- Temperature read-out in °F or °C

- Temperature measure range: -40°C ~ +85°C (-40°F ~ 185°F)

- Relative humidity measure range: 0 ~ 100%

- Temperature measure accuracy:

          - between 15°C ~ +40°C, deviation is ±0.5°C;

          - between -40°C ~ +85°C, deviation is ±1°C

- Broadcasting range: up to 50 m ( 160 ft)

- Operating temperature: 0°C to 50°C

- Storage temperature: -20°C to 60°C

- Battery type: Lithium battery CR2032, 3V, exchangeable

- Dimension: diam. 31 mm x H 15 mm (diam. 1.22 inc x H 0.60 inc)



SOFTWARE SPECIFICATIONS:

- Compatible with iPhone and Android phones

- iOS and Android mobile app available on iOS Store and Google Play

- Requirements: iOS 10.0 or later and Android operating system 9.0 or later

- Languages: English and Italian
